Hioki IM3533 - Page 109

4.4 Judging Measurement Results
101
4
Chapter 4 LCR Function
3
To select the judgment mode.
Disables comparator and BIN measurement.
Enables comparator measurement (p. 102).
Enables BIN measurement (p. 109).
Judgment Mode Setting
When comparator measurement and BIN measurement
are performed, only the first and third parameters can
be set.
The second and fourth parameters become .
4
Press to close the setting screen.
