4.5 Setting Application Settings
127
4
Chapter 4 LCR Function
This function allows you to set measurement conditions (measurement speed and averaging settings) on a
single screen.
When configuring all functionality for a particular measurement range
The settings are the same as described in "4.3 Setting DC Resistance Measurement" (p. 80).
LCR Range Synchronization Function
Settings Screen (Rdc)
1. Select the measurement range you wish to
configure with and and touch .
3. Press to close the setting screen.
When you want to cancel the setting and return to the
previous screen:
Press .
Range Synchronization Function Edit Screen (Rdc)
2. Configure the speed and averaging settings.
See "4.3.6 Setting the Measurement Speed" (p. 98)
"4.3.7 Displaying Average Values (Average set)"
(p. 99)
To Next Page
