10.3 Self Checks
(Self Diagnosis)
267
10
Chapter 10 Setting the SYSTEM
4
Panel Compensation
Complete
Press
to close the setting scree
n.
If the
indication does not appear, the instru-
ment needs to be repaired.
Contact your authorized Hioki distributor or reseller.
Press
to start panel
compensation from
the beginning.
