• In the continuous measurement screen, comparator result output signals other than AND and
panel load signals (LD-VALID
, LD0 to LD6) cannot be used.
See: "Chapter 7 CONTINUOUS Measurement Function" (p. 209)
• Whether the comparator judgment results are reset when the signal changes to EOM (HIGH) or
updated when measurement completes can be selected on the instrument or using a communica-
tion command.
See: "4.5.5 Setting the Delay Time from the Output of Comparator and BIN Judgment Results until Output of
EOM (LOW) and Resetting Judgment Results" (p. 134)
LCR Application Disk - communication commands (
:IO:RESult:RESet)
• For other timing chart times, refer to "12.2.1 LCR Mode" (p. 318).
