14.1 General Specifications
341
14
Chapter 14 Specifications
3.Interface
Display 5.7-inch color TFT, touch panel
Handler interface Equipped as standard
USB interface Equipped as standard, full speed/hi speed compatible
USB memory Measurement conditions, measurement values, and screens can be saved.
Measurement conditions can be loaded.
Supported operations: display of saved measurement values and screens, file deletion, fold-
er creation, and formatting
Optional units Model Z3000 GP-IB Interface (Option)
Model Z3001 RS-232C Interface (Option)
Model Z3002 LAN Interface (Option)
4.Environmental and Safety Specifications
Operating temperature and
humidity
0 to 40°C (32 to 104°F), 20 to 80% RH or less (non-condensating)
Storage temperature and
humidity
-10 to 55°C (14 to 131°F) 20 to 80% RH or less (non-condensating)
Operating environment Indoors, pollution degree 2, altitude up to 2000 m (6562-ft.)
Rated supply voltage AC100 V to 240 V
Rated supply frequency 50/ 60 Hz
Maximum rated power
consumption
50 VA
Dimensions Approx. 330 W × 119 H ×168 D mm (12.99" W ×4.69" H ×6.61" D) (excluding protrusions)
Mass Approx. 3.1 kg (109.3 oz.)
Applicable StandardsSafety
EMC
EN61010
EN61326 Class A
EN61000-3-2
EN61000-3-3
Dielectric strength Between the power wire and ground wire: 1.62 kV AC for 1 minutes
5.Accessories, Options
Accessories Power Cord ......................................................1
Instruction Manual............................................1
LCR Application Disk ......................................1
(Communications instruction manual [PDF format], explanation of communications commands,
USB driver, sample application)
Options Model 9262 Test Fixture
Model 9263 SMD Test Fixture
Model 9677 SMD Test Fixture
Model 9699 SMD Test Fixture
Model L2000 4-Terminal Probe
Model 9140-10 4-Terminal Probe
Model 9143-10 Pincher Probe
Model 9261-10 Test Fixture
Model 9500-10 4-Terminal Probe
Model Z3000 GP-IB Interface
Model Z3001 RS-232C Interface
Model Z3002 LAN Interface
Model 9478 Sheath Type Temperature Probe
Model 9268-10 DC Bias Voltage Unit
Model 9269-10 DC Bias Current Unit
