3.1 When LCR Mode
38
4
Connect the test sample to the 9263 SMD test fixture.
For the connection procedure of the test sam-
ple, refer to the instruction manual supplied
with the fixture.
5
Check the measurement results.
• When you want to judge the measurement results
See: "4.4.1 Judging with Upper and Lower Limit Values
(Comparator Measurement Mode)" (p. 102)
• When you want to save the measurement results
See: "4.5.8 Saving Measurement Results (Memory
function)" (p. 138)
