443
Figure 458 Port setup
3. Configure member ports for a port isolation group as described in Table 132.
4. Click Apply.
5. When the success notification appears, click Close.
Table 132 Configuration items
Item Descri
tion
Isolate group ID Select the ID of the port isolation group to be configured.
Config type
Specify the role of the port or ports in the isolation group.
• Isolated port—Assign the port or ports to the isolation group as an isolated port or
ports.
• Uplink port—Assign the port to the isolation group as the uplink port.
The device does not support uplink ports.
Select port(s)
Select the ports to assign to the isolation group.
To select ports, you can click ports on the chassis front panel. If aggregate interfaces are
configured, they will be listed on the chassis panel.
After selecting Isolated port for Config type, you can select multiple ports to configure.
You cannot configure an isolated port in a port isolation group as the uplink port of the
current or another port isolation group, but you can configure it as an isolated port of
another port isolation group.
