HP Designjet T7200

Left-hand Assemblies
Number in
figure
HP part number Description Cross-reference
1 CQ105-67054 Cartridge Trays
Cartridge Tray on page 301
2 CQ105-67044 Lower Ink Supply Station (without APS
Assembly but including Cartridge Tray)
Ink Supply Station (ISS) on page 297
3 CQ105-67043
Upper Ink Supply Station (without APS
Assembly but including Cartridge Tray)
Ink Supply Station (ISS) on page 297
4 Q1273-60245 ISS to Cartridge Cable N/A
5 CQ105-67050
APS Assembly (includes Pump, Holder and
Relief Valve)
APS Assembly on page 303
6 Q6651-60326 Internal Secondary Spittoon
– Q6651-60315 Left Scan-axis Bracket
ENWW Printer 183
