HP Designjet T7200 - Preventive Maintenance Kits

Preventive Maintenance Kits
Normal printer use means 6,000,000 Carriage Cycles (which corresponds to approximately 100,000 A0 prints
on average). Under normal usage conditions, it will be approximately 5 years before the printer needs
maintenance. If the printer is used more heavily than normal, then it will need maintenance service much
more frequently.
One of the EEROM counters is assigned to counting the number of carriage cycles. When certain components
of the printer exceed this amount, the front panel displays the following message:
“Maintenance #1 required”
The following message is triggered depending on the total quantity of ink spitted in each Spittoon.
“Maintenance #2 required”
Depending on the total turns forward of the drive motor, the following message is shown:.
“Maintenance #3 required”
Once one of the maintenance advised messages is displayed, the preventive maintenance kit must be used to
replace the most worn parts of the printer. See
Printer part removal and installation on page 205.
Preventive Maintenance Kit #1
This Preventive Maintenance Kit #1 contains the following components:
●
Encoder Strip
Encoder Strip and Encoder Sensor on page 282
●
Encoder spring+Nut
Encoder Strip and Encoder Sensor on page 282, step 8
●
Carriage PCA Cover
Carriage PCA on page 277
●
Belt Tensioner Assembly
Scan-Axis Motor on page 309, step 7
●
Cutter Assembly
Cutter Assembly on page 329
●
Redial Retainer Assembly
Installation of the Drive Roller on page 397
●
Line Sensor Cable
Line Sensor Assembly on page 285
●
Air Purges (Setup Printheads)
●
Aerosol foam protector
Line Sensor Assembly on page 285, step 6
●
Carriage Assembly (with Encoder sensor)
Carriage on page 270 (does not include PCA nor Cutter)
●
Ink Supply Tubes and Trailing Cable
Ink Supply Tubes and Trailing Cable on page 286
●
Tubes retaining clip
Cover, Top on page 219, step 7
●
Scraper Assembly and Absorber Foams
Removal of the Service Station Scraper on page 237
●
Scan-Axis Motor
Scan-Axis Motor on page 309
●
Belt Assembly
Belt Assembly on page 327
You must also clean the holes in the Service Station which are located under the Maintenance Cartridge and
check that the Aerosol Fan is functioning correctly.
Preventive Maintenance Kit #2
This Preventive Maintenance Kit #2 contains the following components:
