HP Designjet T7200

5. Remove one screw that secures the Left Cover from underneath at the rear.
6. Remove the Left Cover.
Top Cover
Removal
1. Remove the Right Cover
Right Cover on page 402.
2. Remove the Left Cover
Left Cover on page 403.
3. Remove two screws that secure the Temperature Sensor Plate.
ENWW Top Cover 405
