2. Slide the Window hinges on to the Window.
3. Clip the Window Hinges to the Top Cover.
NOTE: Since the hinges are very hard to clip, you will need to forcefully clip the Window hinges to the
Top Cover.
Cover, Top
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Cover See Cover, Right on page 213.
2. Remove the Left Cover
See Cover, Left on page 215.
ENWW Disassembly order 219
