HP Designjet T7200 - Left Cover

5. Remove one screw that secures the Right Cover from underneath at the rear.
6. Remove the LED from inside the Right Cover.
TIP: Use a flat-ended screwdriver to prise off the plastic holder securing the LED to the inside of the
Right Cover.
7. Remove the Right Cover.
Left Cover
Removal
1. Switch off the stacker and remove the power cable.
ENWW Left Cover 403
