2. Remove the Left Connector Cover.
Front Panel
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Right Connector Cover See Connector Cover, Right on page 224.
2. Remove the Right Smart Roll-loading System Cover
See Smart Roll-loading System Cover, Right
on page 245.
3. Disconnect the Front Panel cable.
4. Disconnect the ferrite clip.
226 Chapter 9 Printer part removal and installation ENWW
