8. Unroute the cable from the right arc.
9. Continue unrouting the cable.
10. Disconnect the far end of the cable from the Main PCA, and remove the cable.
Cutter Assembly
Removal
1. Select Replace cutter from the Service Menu (see
Replace Cutter on page 105) and follow the
instructions on the Front Panel.
ENWW Disassembly order 329
