2. Remove five T-15 screws that secure the Right Trim.
3. Disengage the rubber strip from the hole in the Right Trim.
4. Remove the Right Trim from the printer.
Trim, Left
Removal
WARNING! Switch off the printer and remove the power cable.
1. Remove the Output Platen See Output Platen on page 318.
ENWW Disassembly order 323
