4. Slide down the Safety Temperature Sensor Bracket.
5. Disconnect the cables from the Safety Temperature Sensor.
NOTE: When removing or installing the Safety Temperature Sensor, take care not to damage the
surface of the Heat Roller.
Temperature Sensor PCA
Removal
1. Switch off the stacker and remove the power cable.
2. Open the Front Cover.
ENWW Temperature Sensor PCA 419
