12. Clip the OMAS access cover back into place by sliding one edge of the cover into the slot and then
applying enough pressure to it so you can clip it into the other slot.
13. Perform the following calibrations.
●
OMAS Calibration
See OMAS Calibration on page 130.
●
Paper-advance Calibration
See Paper-advance calibration on page 115.
Encoder Disc and Sensor
Removal
WARNING! Switch off the printer and remove the power cable.
CAUTION: Please handle the Encoder Disc very carefully since any finger prints, scratches or stains could
cause the printer to malfunction.
1. Remove the Left Cover See Cover, Left on page 215.
2. Remove the Left Connector Cover
See Connector Cover, Left on page 225.
3. Remove the Ink Supply Station
See Ink Supply Station (ISS) on page 297.
4. Disconnect the Encoder Sensor cable from the PrintMech PCA.
386 Chapter 9 Printer part removal and installation ENWW
