Introduction
This chapter explains how to use the built-in Service Tests and Service Utilities and what to do if any of the
Service Tests fail.
NOTE: If possible, always perform a Service Test on the component that you are about to replace, just to
make sure that is the component that has failed. If the test on that component passes, there is no need to
replace it.
Diagnostics—self test
Whenever the printer is switched ON, it automatically performs a series of internal self tests and mechanical
initialization sequences. If any of the parts fail, a system error will appear; see
System error codes
on page 37.
Phone support
In certain circumstances, a Call Agent can try and troubleshoot the printer by requesting the Customer to
perform a Service Test via the phone. Using this process, it can be determined whether the printer requires
any on-site maintenance.
Remember that the key combination for the customer to enter the Service Tests and Utilities is different from
the one that the engineer will use.
Service tests (diagnostics)
The following is a list of all internal Service Tests available in the printer. To access these tests, see Entering
the Service Tests menu on page 83.
1. Scan Axis Test
Scan Axis test on page 83.
The purpose of this test is to check the operation of components related to the Scan Axis.
2. Paper Drive Test
Paper Drive test on page 84.
The purpose of this test is to check the operation of components related to the Media Axis.
3. Electronics Module Test
Electronics Module test on page 86.
The purpose of this test is to check the operation of the Formatter.
4. Carriage Assembly Test
Carriage Assembly test on page 87.
The purpose of this test is to check the operation of the Carriage Assembly.
5. IDS Tests
IDS tests on page 89.
The purpose of these tests is to check the operation of the Ink Delivery System.
6. Service Station Test
Service Station test on page 93.
The purpose of this test is to check the operation of the Service Station.
7. Primer Test
Primer test on page 94.
The purpose of this test is to check the operation of the Primer.
8. Aerosol Test
Aerosol test on page 95.
The purpose of this test is to check the operation of the Aerosol Fans.
82 Chapter 5 Service tests and utilities ENWW
