HP Designjet T7200 - Page 239

5. Unroute the Primer Assembly cable from the cable clamps.
6. Disconnect the two Primer Assembly tubes.
7. Remove four T-10 screws that secure the Primer Assembly to the Service Station.
NOTE: Use a short screw driver, less than 10 cm in length.
ENWW Disassembly order 229
