28. Slide out the Ink Cartridges.
29. Disconnect the Air Tubes from the Ink Cartridge Tube Connector.
30. Twist the four latches at the rear of the Ink Cartridge Tube Connector and release the complete
assembly.
NOTE: Be careful not to damage the interconnecting cable.
294 Chapter 9 Printer part removal and installation ENWW
