Huawei Quidway S3900 Series User Manual

Operation Manual – Login
Quidway S3900 Series Ethernet Switches-Release 1510 Chapter 2 Logging in through the Console Port
Huawei Technologies Proprietary
2-11
Note that the level the commands of which are available to users logging into a switch
depends on both the authentication-mode password and the user privilege level
level command, as listed in the following table.
Table 2-7 Determine the command level (B)
Scenario
Authentication
mode
User type Command
Command
level
The user privilege level
level command is not
executed
Level 3
Local authentication
(authentication-m
ode password)
Users logging in
through the
AUX user
interface
The user privilege level
level command is
already executed
Determined
by the level
argument
2.5.2 Configuration Example
I. Network requirements
Assume that you are a level 3 VTY user and want to perform the following configuration
for users logging in through the Console port:
z Authenticate users logging in through the Console port using the local password.
z Set the local password to 123456 (in plain text).
z The commands of level 2 are available to users logging into the AUX user
interface.
z The baud rate of the Console port is 19,200 bps.
z The screen can contain up to 30 lines.
z The history command buffer can store up to 20 commands.
z The timeout time of the AUX user interface is 6 minutes.
