Operation Manual – VLAN VPN
Quidway S3900 Series Ethernet Switches-Release 1510 Chapter 1 VLAN-VPN Configuration
Huawei Technologies Proprietary
1-2
VLAN tag. If the packet already carries a VLAN tag, the packet becomes a dual-tagged
packet. Otherwise, the packet becomes a packet carrying the default VLAN tag of the
port.
1.1.3 Adjusting the TPID Values of VLAN-VPN Packets
Tag protocol identifier (TPID) is a filed of the VLAN tag. IEEE 802.1Q specifies the
value of TPID to be 0x8100.
Figure 1-3 illustrates the structure of the Tag packet of an Ethernet frame defined by
IEEE 802.1Q.
DA SA Tag Frame Load FCS
6 bytes 6 bytes 4 bytes 46 ~1500 bytes 4 bytes
TPID User Priority CFI VLAN ID
2 bytes 3 bits 1bit 12 bits
DA SA Tag Frame Load FCS
4 bytes
TPID User Priority CFI VLAN ID
2 bytes 3 bits 1bit 12 bits
DA SA Tag Frame Load FCS
6 bytes 6 bytes 4 bytes 46 ~1500 bytes 4 bytes
TPID User Priority CFI VLAN ID
2 bytes 3 bits 1bit 12 bits
DA SA Tag Frame Load FCS
4 bytes
TPID User Priority CFI VLAN ID
2 bytes 3 bits 1bit 12 bits
Figure 1-3 The structure of the Tag packet of an Ethernet frame
S3900 series switches adopt the default value of TPID (Ox8100) defined by the
protocol. Other vendors use other TPID values (such as 0x9100 or 0x9200) in the outer
tags of VLAN-VPN packets.
To be compatible with devices coming from other vendors, S3900 series switches can
adjust the TPID values of VLAN-VPN packets based on ports. You can configure the
TPID value of a port connecting to the public network side by yourself. When the port
forwards a packet, the port will replace the TPID value in the outer VLAN tag of this
packet with the user-defined value. Thus, the VLAN-VPN packets sent to the public
network can be recognized by devices of other vendors.
The position of the TPID field in an Ethernet packet is the same as the position of the
protocol type field in a packet without VLAN Tag. Thus, to avoid confusion happening
when the switch forwards or receives a packet, you must not configure the following
protocol type values listed in
Table 1-1 as the TPID value.
Table 1-1 Values of Ethernet frame protocol type in common use
Protocol type Value
ARP 0x0806
IP 0x0800
MPLS 0x8847/0x8848
