Huawei Quidway S3900 Series User Manual

Operation Manual – ACL
Quidway S3900 Series Ethernet Switches-Release 1510 Chapter 1 ACL Configuration
Huawei Technologies Proprietary
1-12
Operation Command Description
Display ACL
information
display acl { all |
acl-number }
Optional
This command can be
executed in any view.
In the case that you specify the rule ID when defining a rule:
z If the rule corresponding to the specified rule ID already exists, you will edit the
rule, and the modified part in the rule will replace the original content, while other
parts remain unchanged.
z If the rule corresponding to the specified rule ID does not exists, you will create
and define a new rule.
z The content of a modified or created rule must not be identical with the content of
any existing rule; otherwise the rule modification or creation will fail, and the
system will prompt that the rule already exists.
If you do not specify a rule ID, you will create and define a new rule, and the system will
assign an ID for the rule automatically.
rule-string: rule information, which can be combination of the parameters described in
Table 1-10.
Table 1-10 Rule information
Parameter Type Function Description
format-type
Link layer
encapsulation
type
Defines the
link layer
encapsulation
type in the
rule
format-type: the value can be
802.3/802.2, 802.3, ether_ii,
or snap.
lsap lsap-code
lsap-wildcard
lsap field
Defines the
lsap field in
the rule
lsap-code: the encapsulation
format of data frames, a 16-bit
hexadecimal number
lsap-wildcard: mask of the
lsap value, a 16-bit
hexadecimal number used to
specify the mask bit
source
{ source-addr
source-mask |
vlan-id }*
Source MAC
address
information
Specifies the
source MAC
address
range in the
rule
source-addr: source MAC
address, in the format of
H-H-H
source-mask: source MAC
address mask, in the format
of H-H-H
vlan-id: source VLAN ID, in
the range of 1 to 4,094
