Operation Manual - QoS&QoS Profile
Quidway S3900 Series Ethernet Switches-Release 1510 Chapter 1 QoS Configuration
Huawei Technologies Proprietary
1-21
1.9.1 Configuration Prerequisites
z ACL rules used for traffic identifying are defined. Refer to the ACL module in the
book for defining ACL rules
z The port that the packets matching with the configurations rules are redirected to
is specified
z The ports that needs this configuration are specified
1.9.2 Configuration Procedure
Table 1-13 Configure redirect
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface interface-type
interface-number
—
Configure redirect
traffic-redirect { inbound |
outbound } acl-rule { cpu |
interface interface-type
interface-number }
Required
Display the parameter
configurations of
redirect
display qos-interface
{ interface-type
interface-number | unit-id }
traffic-redirect
Display all the QoS
settings of the port
display qos-interface
{ interface-type
interface-number | unit-id }
all
Optional
You can execute the
display command in any
view
acl-rule: Applied ACL rules which can be the combination of various ACL rules. The
way of combination is described in
Table 1-9.
 Note:
z The redirect configuration is effective only for the ACL rules whose actions are
permit.
z When packets are redirected to CPU, they cannot be forwarded normally.
z If you set to redirect the traffic to a Combo port which is in down state, the system
automatically redirects the traffic to the up port which is corresponding to the Combo
port.
1.9.3 Configuration Example
z Ethernet1/0/1 of the switch is accessed into the 10.1.1.1/24 network segment
