Huawei Quidway S5600 Series User Manual

Operation Manual – IP Address and Performance Confiugration
Quidway S5600 Series Ethernet Switches-Release 1510
Chapter 1
IP Address Configuration
Huawei Technologies Proprietary
1-4
10001010, 00100110, 000 00000, 00000000
ClassB
138.38.0.0
Subnet mask
255.255.224.0
11111111, 11111111, 111 00000, 00000000
11111111, 11111111, 000 00000, 00000000
Standard
mask
255.255.0.0
Subnet address:
000 Subnet address: 138.38. 0. 0
001 Subnet address: 138.38. 32. 0
010 Subnet address: 138.38. 64. 0
011 Subnet address: 138.38. 96. 0
100 Subnet address: 138.38.128. 0
101 Subnet address: 138.38.160. 0
110 Subnet address: 138.38.192. 0
111 Subnet address: 138.38.224. 0
Subnet
number
Host
number
Subnet address:
10001010, 00100110, 000 00000, 00000000
ClassB
138.38.0.0
Subnet mask
255.255.224.0
11111111, 11111111, 111 00000, 00000000
11111111, 11111111, 000 00000, 00000000
Standard
mask
255.255.0.0
Subnet address:
000 Subnet address: 138.38. 0. 0
001 Subnet address: 138.38. 32. 0
010 Subnet address: 138.38. 64. 0
011 Subnet address: 138.38. 96. 0
100 Subnet address: 138.38.128. 0
101 Subnet address: 138.38.160. 0
110 Subnet address: 138.38.192. 0
111 Subnet address: 138.38.224. 0
Subnet
number
Host
number
Subnet address:
Figure 1-2 Subnet division of the IP address
1.2 Configuring an IP Address
For a VLAN interface, an IP address can be obtained in one of the three ways:
z Manually configured by using the IP address configuration command
z Allocated by the BOOTP server
z Allocated by the DHCP server
The three methods are mutually exclusive and the use of a new method will result
in the IP address obtained by the old method being released. For example, if you
obtain an IP address by using the IP address configuration command, and then
use the ip address bootp-alloc command to apply for an IP address, the
originally configured IP address is deleted and a new IP address will be allocated
by BOOTP for the VLAN interface.
This chapter only introduces how to configure an IP address with the IP address
configuration command. For other two other two methods, refer to the part of
configuring and managing VLAN of this manual.
1.3 Configuring an IP Address for a VLAN Interface
Generally, it is enough to configure one IP address for a VLAN interface. However,
you can configure up to five IP addresses for a VLAN interface so that the interface
can be connected to several subnets. Among these IP addresses, one is the
primary IP address and the others are secondary ones.
Table 1-2 Configure an IP address for a VLAN interface
Operation Command Description
Enter system view
system-view
—
