<Quidway> system-view
System View: return to User View with Ctrl+Z.
[Quidway] acl number 2000
[Quidway-acl-basic-2000] rule permit source 10.1.1.1 0.0.0.255
[Quidway-acl-basic-2000] quit
[Quidway] interface GigabitEthernet1/0/1
[Quidway-GigabitEthernet1/0/1] traffic-limit inbound ip-group 2000 100 exceed
remark-dscp 56
1.9 Configuring Redirect
Refer to 1.1.10 Redirect for the introduction to redirect.
1.9.1 Configuration Prerequisites
z ACL rules used for traffic identifying are defined. Refer to the ACL module in the
book for defining ACL rules
z The port that the packets matching with the configurations rules are redirected to is
specified
z The ports that needs this configuration are specified
1.9.2 Configuration Procedure
Table 1-13 Configure redirect
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface interface-type
interface-number
—
Configure redirect
traffic-redirect inbound
acl-rule { cpu | interface
interface-type
interface-number }
Required
Display the parameter
configurations of
redirect
display qos-interface
{ interface-type
interface-number | unit-id }
traffic-redirect
Display all the QoS
settings of the port
display qos-interface
{ interface-type
interface-number | unit-id }
all
Optional
You can execute the
display command in any
view
acl-rule: Applied ACL rules which can be the combination of various ACL rules. The
way of combination is described in
Table 1-9.
