Huawei Quidway S5600 Series User Manual

Operation Manual – Mirroring
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1 Mirroring Configuration
Huawei Technologies Proprietary
1-4
Function Specifications Related command Link
Supports port
mirroring
mirroring-group
mirroring-group mirroring-port
mirroring-group monitor-port
monitor-port
mirroring-port
Section
1.3.2
“
Configuring
Port Mirroring”
Supports remote
port mirroring
mirroring-group
mirroring-group mirroring-port
mirroring-group monitor-port
mirroring-group reflector-port
mirroring-group remote-probe
vlan
Section
1.3.3
“
Configuring
RSPAN”
1.3 Mirroring Configuration
For mirroring features, see section 1.1 “Overview”.
1.3.1 Configuring Traffic Mirroring
I. Configuration prerequisites
z ACLs for identifying traffics have been defined. For defining ACLs, see the
description on the ACL module in this manual.
z The destination port has been defined.
z The port on which to perform traffic mirroring configuration and the direction of
traffic mirroring has been determined.
II. Configuration procedure
Table 1-3 Configure traffic mirroring
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port view of the
destination port
interface interface-type
interface-number
—
Define the current port as the
destination port
monitor-port
Required
LACP and TCP
cannot be enabled
on the destination
port.
Exit current view
quit
—
Enter Ethernet port view of
traffic mirroring configuration
interface interface-type
interface-number
—
