Quidway S5600 Series Ethernet Switches Chapter 1 QoS Configuration
Huawei Technologies Proprietary
1-17
Operation Command Description
Configure
port-based rate
limit
line-rate outbound
target-rate
Required
Display the
precedence of the
protocol packet
display
protocol-priority
Optional
You can execute the display
command in any view
1.7.3 Configuration Example
z Set rate limit in the outbound direction of GigabitEthernet1/0/1 on the switch
z The limit rate is 1 Mbps (1024 kbps)
Configuration procedure:
<Quidway> system-view
System View: return to User View with Ctrl+Z.
[Quidway] interface GigabitEthernet1/0/1
[Quidway-GigabitEthernet1/0/1] line-rate outbound 1024
1.8 Configuring TP
Refer to 1.1.8 TP for the introduction to TP.
1.8.1 Configuration Prerequisites
z ACL rules used for traffic identifying are defined. Refer to the ACL module in the
book for defining ACL rules
z The limit rate for TP, the actions for the packets within the specified traffic and the
actions for the packets beyond the specified traffic have been specified.
z The ports that needs this configuration is specified
1.8.2 Configuration Procedure of TP
Table 1-12 Configure TP
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface
interface-type
interface-number
—
