Operation Manual – IRF Fabric
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
IRF Fabric Configuration
Huawei Technologies Proprietary
1-7
1.3.3 Specifying the Fabric Port of a Switch
An S5600 series switch has two Cascade ports, which are used to connect the
devices within a Fabric. It is necessary to enable the Fabric function for the Cascade
ports and use local UP port to connect peer DOWN port or use local DOWN port to
connect peer UP port. Otherwise, the Fabric cannot function normally.
Table 1-6 Specify the fabric port
Operation Command Description
Enter system view
system-view
—
Specify the fabric port of a
switch
fabric-port interface-type
interface-number enable
Optional
Note:
Establishing an IRF system requires a high consistency of the configuration of each
device. Hence, before you enable the fabric port, do not perform any configuration for
the port, and do not enable some functions that affect the IRF (such as TACACAS and
BGP) for other ports or globally. Otherwise, you cannot enable the fabric port. Refer to
the error information output by devices for the detail restricts.
1.3.4 Assigning a Unit Name to a Switch
You can assign a unit name to a switch by performing the operations listed in Table
1-7
.
Table 1-7 Assign a unit name to a switch
Operation Command Description
Enter system view
system-view
—
Assign a unit name to a
switch
set unit unit-id name
unit-name
Required
1.3.5 Assigning an IRF Fabric Name to a Switch
Only the switches with the same IRF fabric name can form an IRF fabric.
Table 1-8 Assign a fabric name to a switch
Operation Command Description
Enter system view
system-view
—
