Huawei Quidway S5600 Series User Manual

Operation Manual – Cluster
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
Cluste
r
Huawei Technologies Proprietary
1-15
Operation Command Description
Display state and
statistics
information about a
cluster
display cluster
Display the
information about
the candidate
devices of a cluster
display cluster candidates
[ mac-address H-H-H |
verbose ]
Display the
information about
the cluster
members
display cluster members
[ member-num | verbose ]
Clear the NDP
statistics on a port
reset ndp statistics
[ interface port-list ]
—
1.6 Cluster Configuration Example
1.6.1 Basic Cluster Configuration Example
I. Network requirements
Three switches form a cluster, in which:
z The management device is an S900 series switch.
z The rest are member devices.
The S5600 switch manages the rest two member devices as the management device.
The detailed information about the cluster is as follows.
z The two member devices are connected to GigabitEthernet1/0/2 and
GigabitEthernet1/0/3 ports of the management device.
z The management device is connected to the external network through its
GigabitEthernet1/0/1 port.
z GigabitEthernet1/0/1 port of the management device belongs to VLAN2, whose
interface IP address is 163.172.55.1.
z All the devices in the cluster use the same FTP server and TFTP server.
z The FTP server and TFTP server share one IP address: 63.172.55.1.
z The SNMP site and log host share one IP address: 69.172.55.4.
