Huawei Quidway S5600 Series User Manual

Operation Manual – Mirroring
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1 Mirroring Configuration
Huawei Technologies Proprietary
1-9
[Quidway] mirroring-group 1 local
[Quidway] mirroring-group 1 monitor-port GigabitEthernet 1/0/4
[Quidway] mirroring-group 1 mirroring-port GigabitEthernet 1/0/1 both
1.3.3 Configuring RSPAN
I. Configuration prerequisites
z The source switch, intermediate switch, and the destination switch have been
determined.
z The source port, the reflector port, the destination port, and the remote-probe
VLAN have been determined.
z Required configurations are performed to ensure Layer 2 connectivity between the
source and destination switches over the
remote-probe VLAN.
z The direction of the packets to be monitored has been determined.
z The remote-probe VLAN is enabled.
II. Configuring RSPAN on the source switch
Table 1-8 Configure RSPAN on the source switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and
enter its VLAN view
vlan vlan-id
vlan-id is the ID of the
destination remote-probe
VLAN.
Define the current
VLAN as a
remote-probe VLAN
remote-probe vlan
enable
Required
Exit current view
quit
—
Enter the view of the
ports that connected to
the intermediate switch
or destination switch
interface
interface-type
interface-number
—
Configure the current
port as Trunk
port link-type trunk
Required
By default, the port type is
Access.
Configure Trunk port to
permit packets from
the remote-probe
VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
This setting is required for
source switch ports that
connected with the
intermediate switch or
destination switch.
Exit current view
quit
—
