Huawei Quidway S5600 Series User Manual

Operation Manual – Mirroring
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1 Mirroring Configuration
Huawei Technologies Proprietary
1-10
Operation Command Description
Configure a remote
source mirroring group
mirroring-group
group-id
remote-source
Required
Configure a source
port for remote
mirroring
mirroring-group
group-id
mirroring-port
mirroring-port-list
{ both | inbound |
outbound }
Required
Configure a remote
reflector port
mirroring-group
group-id reflector-port
reflector-port
Required
The remote reflector port must
be of the Access type. LACP
and STP must be disabled on
this port.
After a port is configured as a
reflector port, the switch does
not allow you to perform any of
the following configurations:
z Changing the port type and
its default VLAN ID
z Add it to another VLAN
Configure the
remote-probe VLAN
for the remote source
mirroring group
mirroring-group
group-id remote-probe
vlan
remote-probe-vlan-id
Required
Display the
configuration of the
remote source
mirroring group
display
mirroring-group
remote-source
Optional
This command can be
executed in any view.
 Note:
z To mirror tagged packets, you need to configure VLAN VPN on the reflector port.
z The reflector port cannot forward traffics as a normal port. Therefore, it is
recommended that you use a idle and in-down-state port as the reflector port, and
be careful to not add other settings on this port.
z It is recommended that you do not configure a VLAN as the remote-probe VLAN if
the mac-address max-mac-count 0 command is configured on a port in this VLAN.
Otherwise, remote mirroring may not work properly.
z Be sure not to configure a port used to connect the intermediate and destination
switches as the mirroring source port. Otherwise traffic disorder may occur in the
network.
