[Quidway-acl-basic-2000] rule deny source any
[Quidway-acl-basic-2000] quit
[Quidway] interface gigabitEthernet 1/0/4
[Quidway-GigabitEthernet1/0/4] monitor-port
[Quidway-GigabitEthernet1/0/4] quit
[Quidway] interface gigabitEthernet 1/0/1
[Quidway-GigabitEthernet1/0/1] mirrored-to inbound ip-group 2000
monitor-interface
1.3.2 Configuring Port Mirroring
I. Configuration prerequisites
z The source port is specified and whether the packets to be mirrored are inbound or
outbound is specified: inbound: only mirrors the packets received via the port;
outbound: only mirrors the packets sent by the port; both: mirrors the packets
received and sent by the port at the same time.
z The destination port is specified.
z The group number of the mirroring group is specified.
II. Configuring port mirroring in Ethernet port view
Table 1-5 Configure port mirroring in Ethernet port view (1)
Operation Command Description
Enter system view
system-view
—
Create a port mirroring
group
mirroring-group
group-id local
Required
Enter Ethernet port view
of the destination port
interface interface-type
interface-number
—
Define the current port as
the destination port
monitor-port
Required
LACP and TCP must be
disabled on the destination
port.
Exit current view
quit
—
Enter Ethernet port view
of the source port
interface interface-type
interface-number
—
Configure the source port
and specify the direction
of the packets to be
mirrored
mirroring-port
{ inbound | outbound |
both }
Required
Display parameter
settings of the mirroring
display
mirroring-group { all |
local }
Optional
This command can be
executed in any view.
