Huawei Quidway S5600 Series User Manual

Operation Manual – Port Basic Configuration
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
Port Basic Configuration
Huawei Technologies Proprietary
1-1
Chapter 1 Port Basic Configuration
1.1 Ethernet Port Overview
1.1.1 Types and Numbers of Ethernet Ports
Table 1-1 lists the types and numbers of the ports available on the Quidway S5600
series Ethernet switches.
Table 1-1 Ports on the S5600 series Ethernet switches
Switch model Fixed port Expansion port type
S5624P
S5624P-PWR
24 x 10/100/1000 Mbps electrical
ports and four SFP combo ports
S5624F
24 x 1000 Mbps SFP ports and
four electrical combo ports
S5648P
S5648P-PWR
48 x 10/100/1000 Mbps electrical
ports and four SFP combo ports
10/100/1000BASE-TX
1000Base-SX-SFP
1000Base-LX-SFP
1000Base-LH-SFP
1000Base-T-SFP
10GBase-LR-XENPAK
10GBase-ER-XENPAK
10GBase-CX4-XENPAK
10GBase-LR-XFP
10GBase-ER-XFP
Each Combo optical port corresponds to an Ethernet electrical port, so there are four
port pairs; only one port in a pair can be used at the same time. For the relationship
between the Combo ports and the Ethernet ports, refer to
Table 1-2.
Table 1-2 Combo port list
Switch model Combo port Corresponding port
25 22
26 24
27 21
S5624P/S5624P-PWR/S5624F
28 23
49 46
50 48
51 45
S5648P/S5648P-PWR
52 47
