Quidway S5600 Series Ethernet Switches Chapter 1 QoS Configuration
Huawei Technologies Proprietary
1-24
1.11.3 Clearing Traffic Statistics Information
Table 1-17 Clear traffic statistics information
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface
interface-type
interface-number
—
Clear the statistics of
the traffic matching
with the specified ACL
rules
reset traffic-statistic
inbound acl-rule
Required
The function of clearing is
effective only when the traffic
statistics function is configured
acl-rule: Applied ACL rules which can be the combination of various ACL rules. The
way of combination is described in
Table 1-9.
1.11.4 Configuration Example
z Ethernet1/0/1 of the switch is accessed into the 10.1.1.1/24 network segment
z Perform traffic statistics on packets from the 10.1.1.1/24 network segment
Configuration procedure:
<Quidway> system-view
System View: return to User View with Ctrl+Z.
[Quidway] acl number 2000
[Quidway-acl-basic-2000] rule permit source 10.1.1.1 0.0.0.255
[Quidway-acl-basic-2000] quit
[Quidway] interface GigabitEthernet1/0/1
[Quidway-GigabitEthernet1/0/1] traffic-statistic inbound ip-group 2000
1.12 QoS Configuration Example
1.12.1 Configuration Example of TP and Rate Limit on the Port
I. Network requirement
The enterprise network interworks all the departments through the ports of the Ethernet
switch. The salary query server of the financial department is accessed through
GigabitEthernet1/0/1 whose subnet address is 129.110.1.2. The network requirements
are to limit the average rate of outbound traffic within 640kbps and set the precedence
of packets exceeding the specification to 4.
