Table 1-5 Display configurations of a Voice VLAN
Operation Command Description
Display the
information about
ports on which
Voice VLAN
configuration fails
display voice vlan error-info
Display the voice
VLAN
configuration
status
display voice vlan status
Display the
currently valid OUI
addresses
display voice vlan oui
Display the ports
operating in the
current voice
VLAN
display vlan vlan-id
You can execute the
display command in any
view.
1.4 Voice VLAN Configuration Example
1.4.1 Voice VLAN Configuration Example (Automatic Mode)
I. Network requirements
z Create VLAN 2 and configure it as a voice VLAN.
z Configure GigabitEthernet1/0/1 port as a Trunk port, with VLAN 6 as the default
port.
z GigabitEthernet1/0/1 port can be added to/removed from the voice VLAN
automatically according to the type of the data stream that reaches the port.
II. Configuration procedure
# Create VLAN 2.
<Quidway> system-view
[Quidway] vlan 2
# Configure GigabitEthernet1/0/1 port to be a Trunk port, with VLAN 6 as the default
VLAN.
[Quidway] interface GigabitEthernet1/0/1
[Quidway-GigabitEthernet1/0/1] port link-type trunk
[Quidway-GigabitEthernet1/0/1] port trunk pvid vlan 6
# Enable the voice VLAN function for the port and configure the port to operate in
automatic mode.
