Huawei Quidway S5600 Series - Ssh Client Configuration Example

Operation Manual - SSH Terminal Services
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
SSH Terminal Services
Huawei Technologies Proprietary
1-14
[Quidway-rsa-key-code] public-key-code end
[Quidway-rsa-public-key] peer-public-key end
[Quidway] ssh user client002 assign rsa-key quidway002
# Start the SSH client software on the host which stores the RSA private keys and make
corresponding configuration to establish an SSH connection.
1.1.6 SSH Client Configuration Example
I. Network Requirements
As shown in Figure 1-4,
z Switch A serves as an SSH client with user name as client003.
z Switch B serves as an SSH server, with its IP address 10.165.87.136.
II. Network diagram
PC
IP address ：10.165.87.136
SSH Client
Switch B
SSH Server
Switch A
PC
IP address ：10.165.87.136
Switch B
SSH Server
SSH Client
Switch A
Figure 1-4 Network diagram for SSH client configuration
III. Configuration procedure
1) Configure the client to run the initial authentication.
[Quidway] ssh client first-time enable
2) Configure server public keys on the client.
[Quidway] rsa peer-public-key public
[Quidway-rsa-public-key] public-key-code begin
[Quidway-rsa-key-code] 308186028180739A291ABDA704F5D93DC8FDF84C427463
[Quidway-rsa-key-code] 1991C164B0DF178C55FA833591C7D47D5381D09CE82913
[Quidway-rsa-key-code] D7EDF9C08511D83CA4ED2B30B809808EB0D1F52D045DE4
[Quidway-rsa-key-code] 0861B74A0E135523CCD74CAC61F8E58C452B2F3F2DA0DC
[Quidway-rsa-key-code]
C48E3306367FE187BDD944018B3B69F3CBB0A573202C16
[Quidway-rsa-key-code] BB2FC1ACF3EC8F828D55A36F1CDDC4BB45504F020125
[Quidway-rsa-key-code] public-key-code end
