Huawei Quidway S5600 Series User Manual

Operation Manual – Routing Protocol
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 4 OSPF Configuration
Huawei Technologies Proprietary
4-11
Table 4-2 Basic OSPF configuration
Operation Command Description
Enter system view
system-view
—
Configure the router ID
router id router-id
Optional
If multiple OSPF
processes run on a
router, you are
recommended to use
the router-id keyword
in the following
command to specify
different router IDs for
different processes.
Enable OSPF and enter OSPF
view
ospf [ process-id
[ router-id router-id ] ]
Required
Enter OSPF view.
Enter OSPF area view
area area-id
Required
Configure the network segments
in the area
network address
wildcard-mask
Required
By default, an
interface does not
belong to any area.
 Note:
z The ID of an OSPF process or OSPF multi-instance is unique. That is, the ID of
OSPF multi-instance must be different from any in-use process ID.
z One segment can belong to only one area and you must specify each OSPF
interface to belong to a particular area.
4.4 OSPF Area Attribute Configuration
Area partition in OSPF reduces the number of LSAs in the network and enhances
OSPF scalability. To further reduce routing table size and the number of LSAs in some
non-backbone areas on the edge of the AS, you can configure these areas as stub
areas.
A stub area cannot import any external route. For this reason the concept of NSSA area
is introduced. Type7 LSAs can be advertised in an NSSA area. Type7 LSAs are
generated by ASBRs of the NSSA area, and will be transformed into AS-external LSAs
whey reaching ABRs in the NSSA area, which will then be advertised to other areas.
After area partition, the OSPF route updates between non-backbone areas are
exchanged by way of the backbone area. Therefore, OSPF requires that all the
