Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 2 DHCP/BOOTP Client Configuration
Huawei Technologies Proprietary
2-4
The BOOTP packets are based on user datagram protocol (UDP). To ensure reliable
packet transmission, a timer is triggered when the BOOTP client sends a request
packet to the server. If no response packet from the server is received after the timer
times out, the client resends the request packet. The packet is resent every five
seconds and three times at most. After that, no packet is resent if there is still no
response packet from the server.
2.3 DHCP/BOOTP Client Configuration
An S5600 series Ethernet switch can operate as a DHCP/BOOTP client. In this case,
the IP address of the management VLAN interface is obtained through DHCP/BOOTP.
2.3.1 Prerequisites
Before configuring the management VLAN, you need to create the VLAN
corresponding to the VLAN ID. As VLAN 1 is the default VLAN, you do not need to
create it if you configure VLAN 1 to be the management VLAN.
2.3.2 Configuring a DHCP/BOOTP Client
Table 2-1 Configure DHCP/BOOTP client
Operation Command Description
Enter system view
system-view
Required
Configure a specified
VLAN to be the
management VLAN
management-vlan
vlan-id
Required
By default, VLAN 1 operates
as the management VLAN.
Create the management
VLAN interface and enter
VLAN interface view
interface
vlan-interface vlan-id
Required
Configure the way in
which the management
VLAN interface obtains
an IP address
ip address
{ bootp-alloc |
dhcp-alloc }
Required
By default, no IP address is
assigned to the management
VLAN interface.
2.3.3 Configuration Example
I. Network requirements
To manage the switch QuidwayA remotely, which operates as a DHCP client, through
Telnet, The following are required:
z QuidwayA obtains an IP address through DHCP
z The route between QuidwayA and the remote console is reachable.
To achieve this, you need to perform the following configuration for the switch:
