Operation Manual – Link Aggregation
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
Link Aggregation Configuration
Huawei Technologies Proprietary
1-8
Caution:
z The commands of link aggregation cannot be configured with the commands of port
loopback detection feature at the same time.
z The ports where the mac-address max-mac-count command is configured cannot
be added to an aggregation group. Contrarily, the mac-address max-mac-count
command cannot be configured on a port that has already been added to an
aggregation group.
z MAC-authentication-enabled ports and 802.1x-enabled ports cannot be added to an
aggregation group.
z Mirrored destination ports and remote mirrored reflection ports cannot be added to
an aggregation group.
z Ports configured with blackhole MAC addresses, static MAC addresses or the static
ARP protocol cannot be added to the aggregation group.
z Ports where the IP-MAC address binding is configured cannot be added to an
aggregation group.
z Port-security-enabled ports cannot be added to an aggregation group.
1.2.1 Configuring a Manual Aggregation Group
You can create a manual aggregation group, or remove an existing manual aggregation
group (after that, all the member ports in the group are removed from the ports).
You can manually add/remove a port to/from a manual aggregation group, and a port
can only be manually added/removed to/from a manual aggregation group.
Table 1-1 Configure a manual aggregation group
Operation Command Description
Enter system view
system-view
—
Create a manual
aggregation group
link-aggregation group
agg-id mode manual
Required
Configure a description
for the aggregation
group
link-aggregation group
agg-id description
agg-name
Optional
By default, an aggregation
group has no description.
Enter Ethernet port view
interface interface-type
interface-num
—
Add the port to the
aggregation group
port link-aggregation
group agg-id
Required
Note that:
