Huawei Quidway S5600 Series User Manual

Operation Manual – MSTP
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
MSTP Configuration
Huawei Technologies Proprietary
1-14
Operation Command Description
Configure MSTP
packet format
stp compliance { auto |
dot1s | legacy }
Required
By default, an MSTP packet is
in legacy format.
II. Configuration Example
# Configure the MSTP packet format as dot1s (802.1s).
<Quidway> system-view
[Quidway] interface GigabitEthernet1/0/1
[Quidway-GigabitEthernet1/0/1] stp compliance dot1s
# Restore the MSTP packet format to the default.
[Quidway-GigabitEthernet1/0/1] undo stp compliance
1.2.6 MSTP Operation Mode Configuration
A MSTP-enabled switch can operate in one of the following operation modes:
z STP-compatible mode: In this mode, the protocol packets sent out of the ports of
the switch are STP packets. If the switched network contains STP-enabled
switches, you can configure the current MSTP-enabled switch to operate in this
mode by using the stp mode stp command.
z RSTP-compatible mode: In this mode, the protocol packets sent out of the ports of
the switch are RSTP packets. If the switched network contains RSTP-enabled
switches, you can configure the current MSTP-enabled switch to operate in this
mode by using the stp mode rstp command.
z MSTP mode: In this mode, the protocol packets sent out of the ports of the switch
are MSTP packets, or STP packets if the ports have STP-enabled switches
connected. In this case, the multiple spanning tree function is enabled as well.
I. Configuration procedure
Table 1-8 Configure MSTP operation mode
Operation Command Description
Enter system view
system-view
—
Configure the
MSTP operation
mode for the
switch
stp mode { stp | rstp |
mstp }
Required
A MSTP-enabled switch
operates in the MSTP mode
by default.
