Operation Manual – ACL
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1
ACL Configuration
Huawei Technologies Proprietary
1-8
Parameter Type Function Description
source
{ sour-addr
sour-wildcard |
any }
Source
address
information
Specifies the
source address
information in
the rule
sour-addr sour-wildcard is
used to specify the source
address of the packet,
expressed in dotted decimal
notation. sour-wildcard can
be 0, which represents a
host address.
any represents any source
address.
destination
{ dest-addr
dest-wildcard |
any }
Destination
address
information
Specifies the
destination
address
information in
the rule
dest-addr dest-wildcard is
used to specify the
destination address of the
packet, expressed in dotted
decimal notation.
dest-wildcard can be 0,
which represents a host
address.
any represents any
destination address.
precedence
precedence
Packet
precedence
Packet priority
Value range: 0 to 7
tos tos
Packet
precedence
ToS priority
Value range: 0 to 15
dscp dscp
Packet
precedence
DSCP priority
Value range: 0 to 63
fragment
Fragment
information
Specifies that
the rule is
effective for
non-initial
fragment
packets
—
time-range
time-name
Time range
information
Specifies the
time range in
which the rule is
active
—
Note:
sour-wildcard/dest-wildcard is the complement of the wildcard mask of the
source/destination subnet mask. For example, you need to input 0.0.255.255 to specify
the subnet mask 255.255.0.0. The arguments can be set as 0 to represent the host IP
address.
To define DSCP priority, you can directly input a value ranging from 0 to 63, or input a
keyword listed in
Table 1-5.
