z If a fabric port of a switch is connected to a non-fabric port, the switch will not
receive DISC packets from the peer. In this case, the switch cannot join the
fabric.
z If the switch can receive DISC packets sent by the peer, the FTM module
determines whether peer sending ports correspond to local receiving ports
according to information in the packet. That is, if a DISC packet received by the
left port of the switch is sent by the right port of the peer device, the packet is
regarded legal. Otherwise, the packet is regarded illegal and is discarded.
z If the maximum number of devices allowed by the fabric is reached, the devices
in the fabric do not send DISC packets and discard the received DISC packets.
This prevents new devices from joining the fabric.
z After receiving a DISC packet from a directly connected device, a device in a
fabric checks whether the device information (that is, the Fabric name and
software version) contained in the packet and those of its own are the same. If
not, the received DISC packet is illegal and will be discarded.
z If authentication is enabled in the fabric, the current device in the fabric
authenticates received packets sent by new directly connected devices. Packets
that fail to pass the authentication will be discarded.
1.2.3 Prompt Information Analysis and Solution
The IRF Fabric peer detection function outputs different prompt information according
to the connection conditions of the devices within the Fabric. You can refer to the
following table to perform corresponding adjustment and maintenance for the Fabric.
Table 1-1 Prompt information analysis and solution
Prompt Analysis Solution
normal it indicates the fabric operates properly
temporary it indicates the port status is changing
redundance port
it indicates the port is the redundant
port in fabric ring topology
The “normal”,
“temporary” and
“redundance port”
information do not
mean a device or a
fabric operates
improperly. No
measure is needed
for any of these three
types of information
Tw
sam
the right port
l
o fabric ports of the
e device (that is,
and the
eft port) are
connected.
Pull out one end of
the cable and connect
it to a fabric port of
another switch.
connection error
The port
matching
three kinds
of errors
The left and right fabric
ports of two devices
are not connected in a
crossed way.
Connect the left and
right ports of two
devices in a crossed
way.
