Huawei Quidway S5600 Series User Manual

Operation Manual – FTP and TFTP
Quidway S5600 Series Ethernet Switches-Release 1510 Chapter 1 FTP and TFTP Configuration
Huawei Technologies Proprietary
1-15
1.2.2 TFTP Configuration
I. Prerequisites
A switch operates as a TFTP client and a remote PC as the TFTP server. The network
operates properly, as shown in
Figure 1-4.
II. Basic TFTP configurations
Table 1-10 Basic TFTP configurations
Operation Command Description
Download a file
through TFTP
tftp tftp-server get
source-file [ dest-file ]
Optional
Upload a file
through TFTP
tftp tftp-server put
source-file [ dest-file ]
Optional
Enter system view
system-view
—
Set the TFTP file
transmission mode
tftp { ascii | binary }
Optional
By default, the binary file
transmission mode is
adopted.
Specify the ACL
adopted when a
switch attempts to
connect a TFTP
server
tftp-server acl acl-number
Optional
III. Specifying the source interface and source IP address for a TFTP client
You can specify the source interface and source IP address for a switch acting as a
TFTP client, so that it connects with a remote TFTP server through the IP address of
the specified interface or the specified IP address.
Table 1-11 Specify the source interface and source IP address for a TFTP client
Operation Command Description
Specify the source
interface so that the TFTP
client uses it to connect
with a TFTP server for the
next time
tftp tftp-server
source-interface
interface-type
interface-number { get
source-file [ dest-file ] | put
source-file-url [ dest-file ] }
Optional
Specify the source IP
address so that the TFTP
client uses it to connect
with a TFTP server for the
next time
tftp tftp-server source-ip
ip-address { get source-file
[ dest-file ] | put source-file-url
[ dest-file ] }
Optional
