Oil pressure adjustment valve disassembly
• Disassemble the following parts:
- screw (1)
- Seal (2)
- Spring (3)
- Adjuster piston (1)
Oil pressure adjustment valve assembly
• Grease adjuster piston and spring
Consumables
Castrol GPS SAE 10W-40 Engine oil
• Assemble the following parts:
- Adjuster piston (4)
- Spring (3)
- Seal (2)
- Fit screw (1).
Tightening torque gures
Oil adjustment valve screw plug onto crankcase
M14 x 1, with sealing ring Grease
thread
15 Nm / 1,5 Kgm / 11,06 ft/lb
Oil pressure adjustment valve replacement
