Husqvarna TE511 - Brake System Specifications

A.51
st
edition (08-2010) _Rev. 11-2010
GENERAL INFORMATION
Brakes
Front (TC - TE - TXC)
Fixed disc type “WAVE” Ø 10.24 in (260 mm) with hydraulic control and floating calliper.
Brake pad surface area ........................................ 2.56 sq.in (16.50 sq.cm)
x 2
Front (SMR)
“WAVE” Ø 9.45 in (240 mm) with hydraulic control and oating calliper.
Brake pad surface area .......................................... 1.53 sq.in (9.90 sq.cm) x 2
Separate hydraulic circuit and master cylinder with control on right handlebar.
Rear
Fixed disc type “WAVE” Ø 9.45 in (240 mm) with hydraulic control and floating calliper
Brake pad surface area ......................................................... 1.82 sq.in (11.76 sq.cm) x 2
Separate hydraulic circuit, pedal and master cylinder on right side of vehicle.
Wheels
Rims
Front (TC - TE - TXC) ........................................................ in light alloy: 1.6x21”
Front (SMR) ....................................................................... in light alloy: 3.5x17”
Rear (TC) ........................................................................ in light alloy: 2.15x19”
Rear (TE - TXC) .............................................................. in light alloy: 2.15x18”
Rear (SMR) ..................................................................... in light alloy: 4.25x17”
Tyres
(TC)
Front ................................................................................................ 80/100x21”
Rear .................................................................................................. 110/90x19”
(TXC)
Front ................................................................................................ 80/100x21”
Rear ................................................................................................ 110/100x18”
(TE)
Front .................................................................................................. 90/90x21”
Rear .................................................................................................. 140/80x18”
(SMR)
Front ................................................................................................ 120/70x17”
Rear .................................................................................................. 150/60x17”
Cold tyre pressure
Front
TC ............................................................ 12.8 ÷ 14.22 psi (0.9 ÷ 1.0 Kg/sq.cm)
TE - TXC (*) ............................................. 12.8 ÷ 14.22 psi (0.9 ÷ 1.0 Kg/sq.cm)
TE (%) ........................................................................ 15.65 psi (1.1 Kg/sq.cm)
SMR (*) ....................................................................... 19.91 psi (1.4 Kg/sq.cm)
SMR (▲) ....................................................................... 25.6 psi (1.8 Kg/sq.cm)
SMR (&) ...................................................................... 28.45 psi (2.0 Kg/sq.cm)
Rear
TC .............................................................11.38 ÷ 12.8 psi (0.8 ÷ 0.9 Kg/sq.cm)
TE - TXC (*) ..............................................11.38 ÷ 12.8 psi (0.8 ÷ 0.9 Kg/sq.cm)
TE (%) ........................................................................ 14.22 psi (1.0 Kg/sq.cm)
SMR (*) ....................................................................... 22.76 psi (1,6 Kg/sq.cm)
SMR (▲) ........................................................................ 28.45 psi (2 Kg/sq.cm)
SMR (&) ...................................................................... 31.29 psi (2,2 Kg/sq.cm)
(*) Racing use - (%) Road use - (▲) Rider only - (&) Rider and passenger
