GENERAL INFORMATION
Electrical components location (TC)
The ignition system includes the following elements:
- Generator on the inner side of L.H. crankcase half cover;
- Electronic ignition coil with integrated spark plug cap positioned on cylinder head;
- Electronic control unit under the saddle;
- Spark plug on cylinder head;
- Starter motor in front of engine cylinder;
- Starter contactor positioned under saddle, on rear chassis;
- Potentiometer on throttle body;
- Voltage regulator located at the back of the steering tube.
The electrical system includes the following elements:
- 12V-3Ah battery under the saddle:
- A 30A fuse positioned on the starter contactor;
- Fuel pump relay positioned on the front left side, under the air box:
- Coolant temperature sensor;
- Fuel pump inside the tank.
- Condenser
Electrical components location (TXC)
The ignition system includes the following elements:
- Generator on the inner side of L.H. crankcase half cover;
- Electronic ignition coil with integrated spark plug cap positioned on cylinder head;
- Electronic control unit under the saddle;
- Spark plug on cylinder head;
- Starter motor in front of engine cylinder;
- Starter contactor positioned under saddle, on rear chassis;
- Potentiometers on throttle body;
- Voltage regulator located at the back of the steering tube.
The electrical system includes the following elements:
- 12V-6Ah battery under the saddle;
- A 30A fuse positioned on the starter contactor;
- Fuel pump relay positioned on the front left side, under the air box;
- Electric fan relay, on chassis right-hand side;
- Electric fan;
- Coolant temperature sensor;
- Fuel pump inside the tank.
- Condenser
Electrical components location (TE-SMR)
The ignition system includes the following elements:
- Generator on the inner side of L.H. crankcase half cover;
- Electronic ignition coil with integrated spark plug cap positioned on cylinder head;
- Electronic control unit under the saddle;
- Spark plug on cylinder head;
- Starter motor in front of engine cylinder;
- Starter contactor positioned under saddle, on rear chassis;
- Potentiometers on throttle body;
- Voltage regulator located at the back of the steering tube.
The electrical system includes the following elements:
- 12V-6Ah battery under the saddle;
- Turning indicator asher at the front end, below the headlamp fairing;
- Fuel pump relay and main relay positioned on the front left side, under the air box;
- Electric fan relay, on the right side, under the air box;
- Electric fan;
- A 10A (lights) fuse positioned below the headlamp fairing and a 30A (main) fuse positioned on the starter contactor;
- Coolant temperature sensor;
- Lambda sensor;
- Headlamp with 12V-35W twin halogen bulb and 12V-5W parking light bulb;
- LED tail light with stop light bulb;
- 12V-6W turning indicator bulbs;
- Fuel pump inside the tank.
- Odometer.
- Condenser
