Husqvarna TE511 - Right-Hand Switch (TC)

M.41
H06453
R
Bk
Bk/G
B
B/Bk
Bk/G
ELECTRICAL SYSTEM
1
st
edition (08-2010)_Rev. 11-2010
Right-hand switch (TC)
1. Engine start button
2. Double map push-button
Colour coding key
Bk ................. Black
R ................... Red
B ................... Blue
G ................... Green
Br-Bk ............. Brown-Black
Bk-G ............. Black-Green
B-Bk .............. Blue-Black
