Engine removal
- Remove lower tank, throttle body, chain, and exhaust system as described
in the relevant paragraphs.
- Loosen screw (1) positioned onto pump body, and drain off cooling sys-
tem.
- Loosen clamps (2), and remove engine cooling hoses (3), (4) and (5).
- Loosen screw (6) (with an 8 mm wrench), and detach ground cable (8).
To loosen the nut (7) retaining the "Motor positive" cable (9), it is neces-
sary to use two 8 mm wrenches: one to hold the lock nut (7a) and the other
to loose the nut (7) retaining the cable.
This operation is required to prevent stud bolt removal.
