Husqvarna TE511 - Page 94

E.36
H02495
11
10
H02497
14a
14
H02498
18
15
16
19
H02496
13
12
1
st
edition (08-2010) _Rev. 11-2010
GENERAL PROCEDURES
- Loosen screw (10) (with a 8 mm wrench), and remove cover (11).
- Loosen screw (12) (with a 8 mm wrench), and disconnect clamp (13) from
engine.
- Loosen the three screws (14) (with a 8 mm wrench), and disconnect clutch
actuator (14a).
- Disconnect spark plug cap/coil (16) connector (15), loosen screw (18) (with
a 8 mm wrench), and disconnect ground cable (19).
